Low Speed refrigerated Centrifuge Machine with Microplate Rotor ,tabletype large volume centrifuge

Low Speed refrigerated Centrifuge Machine with Microplate Rotor ,tabletype large volume centrifuge

MOQ: 1 set
Price: negotiable
Standard Packaging: 3ply Wooden Case
Supply Capacity: 500 sets per month
Detail Information
Place of Origin
China
Brand Name
CenLee
Certification
CE, ISO9001/13485
Model Number
TDL5M
Name:
TDL5M Table-type Low Speed Refrigerated Centrifuge
Power Supply V (Hz):
220/110 (50/60), 18A, Single Phase
Max. RPM::
6000
Max. RCF::
5120 X G
Max. Capacity::
1000ml
Temp. Control::
-20oC-40oC
Minimum Order Quantity:
1 set
Price:
negotiable
Packaging Details:
3ply Wooden Case
Supply Ability:
500 sets per month
High Light:

6000RPM Low Speed Centrifuge Machine

,

18A Low Speed Centrifuge Machine

,

1000ml microplate centrifuge

Product Description
TDL5M Table-type Low Speed Refrigerated Centrifuge, large volume centrifuge
Features
  • Suitable for a variety of application of radio-immunity, water treatment, biochemistry, seperation and purification of blood, etc.
  • Microcomputer control, drived by high frequency conversion motor without powde pollution for long service life, various rotors with tube racks and adapters for your diverse separation needs,. Large LCD or 0.8 LED display for your option.
  • User-friendly operational panel. Programable operation function ensures operaters can input speed, time, RCF, accelaration and braking rates at any time. With LCD display, up to 25 protocols can be stored, modified and recalled.
  • 9 accelaration and 10 braking rates (0 is for free brake) and 3-level damping system ensure the best seperation result.
  • Various protection devices including over-speed, misoperation, speed fault, converter fault, lid lock, stainless steel chamber, imbalance shutdown, etc. to ensure the maximum operational safety.
Specifications
Benchtop Low Speed Large Capacity Refrigerated Centrifuge, without rotor
Model TDL5M
Max.Speed (r/min) 6000
Max. RCF (x g) 5120
Max. Capacity (ml) 4 x 750
Control Microprocessor
Drive AC Frequency Conversion Motor
Accel/Decel Rates 10/10
Speed Range (r/min) 50-6000
Speed Control Accuracy (r/min) ±20
Temp. Set Range (°C) -20 to +40
Temp. Control Accuracy(°C) ±1
Timer Range(hour:min:sec) 0-99:59:59
Noise (dB) ≤ 58
Power Supply V (Hz) 220/110 (50/60), 18A, single phase
Dim. (W x D x H) mm 700 x 660 x 410
Weight (kg) 95
Rotors
Rotor Type Rotor No.

Max. Capacity

(place x ml)

Max. Speed

(rpm)

Max. RCF

(x g)

Tube Size

(Range, ml)

Adapters for smaller tubes
Fixed Angle Rotor 1 12 x 10 6000 5120 1.5-10 Available
Swing-out Rotor(250ml) with round buckets 2 4 x 250 4000 3500 5-250 N/A
adapter 4 x 50 4000 3500 50 N/A
adapter 4 x 4 x 10 4000 3500 10 N/A
adapter 4 x 10 x 5 4000 3500 5 N/A

Swing-out Rotor with tube holders 3 4 x 100 5000 4390 0.2-100 Available
Swing-out Rotor with tube holders 4 8 x 50 4200 3100 5-750 Available
      with tube holders 4 4 x 50       N/A
       with tube holders 4 32 x 15       N/A
        with tube holders 4 24 x 15       N/A
        with tube holders 4 16 x 15       N/A
        with tube holders 4 8 x 100       N/A
Swing-out Rotor 5 48/40 x 7 4200 2810 7 N/A
Swing-out Rotor  6 64/72 x 7 4000 3200 7

N/A

Microplate Rotor 7 2 x 2 x 96wells 4000 2200 0.2 N/A
