TGL-16M 16000rpm High Speed Centrifuge with 21532xg Fixed Angle Rotor and 60ml Capacity Refrigerated Laboratory Centrifuge

Name: TGL-16M 16000rpm High Speed Centrifuge with 21532xg Fixed Angle Rotor and 60ml Capacity Refrigerated Laboratory Centrifuge
Brand: Changsha CenLee Technology Co., Ltd,
SKU: TGL-16
Price: 1 USD
Availability: InStock

Brand Name:	CENLEE
Model Number:	TGL-16
MOQ:	1
Price:	$1,000

Detail Information

Product Description

Detail Information

Place of Origin:

Hunan, China

Max Speed:

16000rpm

Max RCF:

21532*g

Max Capacity:

60ml

Speed Accuracy:

±20r/min

Temperature Range:

-20℃~+40℃

Temperature Accuracy:

±1℃

Power Supply:

AC 220V 50Hz 10A

Power:

700W

Machine Noise:

≤55dB(A)

Chamber Diameter:

Φ250

Fastest Acc/Dec Time:

13~30s

Dimensions:

295*400*360mm

Net Weight:

36kg

Timing Range:

0-99min

Rotor Capacity:

24*1.5/2.2ml, 12*1.5/2.2ml, 12*5ml, 4*8*0.2ml PCR Tubes

Highlight:

16000rpm High Speed Centrifuge

21532xg Refrigerated Centrifuge

60ml Capacity Laboratory Centrifuge

Product Description

TGL-16M 16000rpm Fixed Angle Rotor Table Type High Speed Centrifuge Refrigerated

The TGL-16M is a high-speed refrigerated centrifuge with a maximum speed of 16000rpm, designed for laboratory applications requiring precise temperature control and high centrifugal force.

Technical Specifications

Model	TGL-16	Timing Range	0-99min
Maximum Speed	16000r/min	Power Supply	AC 220V 50Hz 10A
Maximum RCF	21532×g	Machine Noise	≤55dB(A)
Maximum Capacity	60ml	Power	700W
Speed Accuracy	±20r/min	Chamber Diameter	Φ250
Temperature Range	-20℃~+40℃	Fastest Acc/Dec Time	13~30s
Temperature Accuracy	±1℃	Dimensions	295400360mm
Net Weight	36kg

Rotor Specifications

Rotor Type	No.	Capacity	Max Speed (r/min)	Max RCF (×g)
Main Machine	TGL-16		16000	21532
Angle Rotor	NO.1	24*1.5/2.2ml	15000	21532
Angle Rotor	NO.2	12*1.5/2.2ml	16000	17800
Angle Rotor	NO.3	12*5ml	12000	10142
Angle Rotor	NO.4	480.2ml PCR tubes	15000	13800

TGL-16M High Speed Centrifuge Refrigerated

TGL-16M Technical Specifications Diagram
