MOQ: | 1 set |
Standard Packaging: | 3ply Wooden Case |
Supply Capacity: | 500 sets per month |
CENLEE16R 16600rpm Fixed Angle Rotor Table Top High Speed Centrifuge Machine For Medical Use
1. Microprocessor controlled for stable system function.
2. Large LCD display with humanized operation interface by touching screen and key pads, either or both.
3. The set parameters can be changed directly during running with no need to stop first.
4. Drived by frequency conversion motor with FOC vector control system for more exactness and lower noise.
5. 9 kinds of Accel profiles, 10 kinds of Decel profiles, and 3 groups of damping with special NR rubber to avoid sample suspension for best separation results.
6. Steel housing coated by power can not only uniform outer surface but also resist corrosion and scratch.
7. 304 quality stainless steel chamber for long durability and easy cleaning.
8. Rubber isolation ring with unique design and excellent performance can avoid condensate water to protect the motor.
9. Non-Fluorine and imported compressor unit with environmental refrigerant for fast refrigeration and low noise. The rotor can be precooled at rest with unique precooling design (only for refrigerated centrifuges).
10. Both mechanical and electronic door lock are available for high reliability.
11. Several proteciton devices such as overspeed, overtemperature, lid-lock, imbalance and so on to ensure safety.
12. The time will display in seconds when the remaining running time is less than 1 minute.
13. Good temperature control can ensure all rotors maintain at 4 ℃ during its max speed (only for refrigerated centrifuges).
14. Instant and continuous centrifugation for option.
TECHNICAL PARAMETER
Benchtop High Speed Refrigerated Centrifuge, without Rotors | |
Model | CenLee16R |
Max.Speed (r/min) | 16600 |
Max. RCF (x g) | 21532 |
Max. Capacity (ml) | 600 (6 x 100ml) |
Control | Microprocessor |
Drive | AC Frequency Conversion Motor |
Accel/Decel Rates | 10/10 |
Speed Range (r/min) | 100-16600 |
Speed Control Accuracy (r/min) | ±20 |
Temp. Set Range (°C) | -20 to +40 |
Temp. Control Accuracy(°C) | ±1 |
Timer Range(hr:min:sec) | 0-99:59:59 |
Noise (dB) | ≤ 55 |
Chamber Dia.(mm) | 280 |
Power Supply V (Hz) | 220/110 (50/60), 10A |
Dim. (W x D x H) mm | 550 x 530 x 360 |
Weight (kg) | 68 |
ROTORS & ADAPTORS
|
